8.0 inch TFT
| Name: | 8.0 inch TFT |
|---|---|
| Product name | 8.0 inch TFT display |
| Model number | JRXTFT8.0-1 |
| Display resolution | 800 X 600 |
| Display mode | IPS |
| Outline size | 199.0 x 157.0 x 7.87mm |
| Viewing size | 163.0 x 122.50mm |
| Backlight | LED white |
| Brightness | 730cd/m² |
| Contrast | 1000:1 |
| Interface | 24 bit RGB |
| Driver IC | JD9165BA |
| Operation voltage | 3.3V |
| PIN | 50P |
Product Detail
