OLED 0.96 inch
| Name: | OLED 0.96 inch |
|---|---|
| Product name | 0.96 inch OLED module |
| Model number | JRXOL0.96MM |
| Dots format | 128 x 64 |
| Display mode | Passive Matrix |
| Outline size | 27.5 x 27.8 x 3.0mm |
| Active area | 21.7 x 11.2 mm |
| Pixel pitch | 0.17 x 0.17mm |
| Interface | I2C |
| Driver duty | 1/64 duty |
| Driver IC | SSD1306 |
| Operating Temperature | -40 ~85° |
| Display color | Monochrome ( White/ blue / Yellow ) |
| Operation voltage | 3-5V |
Product Detail
0.96 inch OLED modulePre:OLED 2.23 inch Next:OLED 1.54 inch
